Carbon fiber is a fiber primarily composed of orientated carbon atoms.  A typical carbon fiber is produced in a fiber tow form consisting of numerous fiber filaments that can range from 5-10 micrometers in diameter.  Carbon fibers have multiple advantages as an engineered material:
Available in various grades for different applications including high strength, standard to high modulus (33Msi – 55Msi) and small to large tow (1.5K – 48K).
| Grade | Fiber Type | Yield Tex (g/1000m) | Tensile Strength | Tensile Modulus | Elongation (%) | Density (g/cm3) | Filament Diameter (μm) | |||
| Ksi | MPa | Msi | GPa | 1.5 | 1.8 | 7 | ||||
| Standard Modulus | TC33 |
1.5K 3K 6K |
100 200 400 |
500 | 3450 | 33 | 230 | 1.7 | 1.8 | 7 |
| TC35R |
12K 24K 48K |
800 1600 3200 |
580 | 4000 | 35 | 240 | 1.7 | 1.8 | 7 | |
| TC35 |
3K 6K |
200 400 |
580 | 4000 | 35 | 240 | 1.7 | 1.8 | 7 | |
|
12K 24K 48K |
800 1600 3200 |
620 | 4278 | 35 | 240 | 1.8 | 1.8 | 7 | ||
| TC36P |
12K 24K |
800 1600 |
710 | 4900 | 36 | 250 | 2.0 | 1.8 | 7 | |
| TC780 |
12K 24K |
800 1600 |
780 | 5380 | 36 | 250 | 2.2 | 1.8 | 7 | |
| Intermediate Modulus | TC42S |
12K 24K |
440 880 |
825 | 5690 | 42 | 290 | 2.0 | 1.81 | 5.1 |
| TC880 |
12K 24K |
780 1560 |
880 | 6072 | 42 | 290 | 2.1 | 1.8 | 6.7 | |
| High Modulus | TC55 |
12K 24K |
420 840 |
640 | 4400 | 55 | 380 | 1.2 | 1.79 | 5.0 |
FPC is the only company in the world that can produce carbon fiber from crude oil to fiber carbonization.
Our carbon fiber is the most stable and reliable source available.
